TE Connectivity 57-Way Pin Contact Plug

The TE Connectivity 57-Way Pin Contact Plug (206437-1) is a highly efficient and reliable connector designed for commercial, signal processing, and power management applications. Featuring a 57-position straight free-hanging configuration with pin-type contacts, this plug is crafted for durability and ease of use.

Constructed from UL94V-0 rated black thermoplastic, the connector ensures robust performance while remaining lightweight. The series 2 connector is compatible with size 20 DF (precision formed) and size 20 DM (screw-machined) pin contacts, with a maximum current carrying capability of 7.5A.

Key Features

• Quick Connect/Disconnect: Equipped with thread assist and positive detent coupling for swift and secure connections.
• Polarized Design: Ensures proper mating of connector halves for error-free assembly.
• Keyed Mating Alignment: Provides precise alignment during connection.
• Threaded Coupling: Offers secure mating retention.
• Contact Protection: Shields contacts from damage during handling and use.

Applications

This connector is ideal for a variety of industrial applications, including commercial equipment and power management systems. Its high-performance design makes it a trusted choice for professionals requiring dependable connectivity solutions.

Technical Specifications

• Product Range: CPC Series 2
• Circular Connector Shell Style: Cable Mount Plug
• No. of Contacts: 57
• Circular Contact Type: Crimp Pin – Contacts Not Supplied
• Coupling Style: Threaded
• Connector Body Material: Thermoplastic
• Insert Arrangement: 23-57
