VISATON 3x7cm 3W Oval Full-Range Driver, 8 Ohm
Compact VISATON full-range driver for clear audio in TVs & PCs. 3W RMS, 160Hz-12kHz response, splash-resistant (IPX4).
The VISATON 3x7cm 3W Oval Driver delivers balanced frequency response and clear high-range reproduction in an exceptionally compact form. Featuring a neodymium magnet system, this full-range driver is ideal for installations where space is at a premium, such as in TVs and PCs. With a nominal impedance of 8 ohms and RMS output power of 3W, it ensures reliable performance for various audio applications.
Key Features
- Compact Design: Neodymium magnet system enables an ultra-small footprint (70x30x19mm).
- Balanced Sound: Frequency response from 160Hz to 12kHz ensures clear audio reproduction.
- Versatile Use: Suitable for built-in speaker applications in audio, commercial, educational, and public settings.
Specifications
- Output Power: 3W RMS
- Nominal Impedance: 8 Ohms
- Frequency Response: 160Hz - 12kHz
- Mean SPL: 78dB
- Resonant Frequency: 300Hz
- Excursion Limit: ±2.4mm
- Connections: Solder lugs (Lötfahnen, 2.4x0.3mm)
- Cutout Diameter: 13.5mm
- Operating Temperature: -20°C to 70°C
- IP Rating: IPX4 (splash-resistant)
- Dimensions: 70mm (L) x 30mm (W) x 19mm (D)
- Weight: 25g
Perfect for integration into compact audio systems, this VISATON driver combines efficiency, durability, and high-quality sound in a minimalist design.
Need larger quantities? Need additional quantities? Get in touch and we'll arrange it for you.
- Audio systems
- TVs
- PCs
- Commercial installations
- Output Power: 3W RMS
- Nominal Impedance: 8 Ohms
- Frequency Response: 160Hz - 12kHz
- Mean SPL: 78dB
- Resonant Frequency: 300Hz
- Excursion Limit: ±2.4mm
- Connections: Solder lugs (Lötfahnen, 2.4x0.3mm)
- Height of Winding: 3.6mm
- Cutout Diameter: 13.5mm
- Operating Temperature: -20°C to 70°C
- IP Rating: IPX4
- Dimensions (HxWxD): 70x30x19mm
- Weight: 25g
