WAGO 224-201 Lighting Connector, 2.5mm, Grey
Secure tool-free WAGO connector for solid & stranded wires (0.5–2.5mm², 24A, 400V). Ideal for lighting & industrial use.
The WAGO 224-201 Lighting Connector is designed to connect solid conductors with fine-stranded conductors effortlessly, making it an ideal solution for household and similar electrical applications in buildings. Approved as independent equipment according to EN 60998, this connector ensures reliable and secure connections without requiring any tools for installation. Simply press the blocks to connect fine-stranded cables.
Constructed with high-quality materials, this lighting connector features tin-plated copper contacts for optimal conductivity and durability. Its compact design (8mm x 15.5mm x 42mm) ensures it fits seamlessly in tight spaces, while the side-entry wiring type simplifies installation.
Applications
- Industrial use
- Communication and networking setups
- Lighting installations
- Security systems
- Signalling equipment
- HVAC applications
Specifications
- Wire Size: 0.5–2.5mm² (Lighting Side - Solid & Fine Stranded)
- Current Rating: 24A
- Voltage Rating: 400V
- Material: Tin-plated copper contacts
- No. of Contacts: 1
- Connector Type: Terminal Block, Standard
- Connector Mounting: Cable Mount
- Wire Size AWG: 16–20AWG
- Colour: Grey
Technical Specifications
- Industrial electrical connections
- Communication & networking setups
- Lighting installations
- Security systems
- Ask Claude, ChatGPT or Perplexity to find the right tool, with our live prices and stock.
- Get a ready-made basket: one link puts everything in your basket here.
- You always pay securely here: your assistant never sees your card.
- Product Range: 224
- Wire Size: 0.5-2.5mm²
- Current Rating: 24A
- Voltage Rating: 400V
- Dimensions: 8mm x 15.5mm x 42mm (W x H x D)
- Material: Copper (Tin-plated contacts)
- No. of Contacts: 1
- Connector Type: Terminal Block, Standard
- Connector Mounting: Cable Mount
- Wire Size (AWG): 16-20
- Colour: Grey
- Weight: 900g
