WAGO DIN Rail Relay Module SPDT 24VAC 16A

The WAGO 788 Series DIN Rail Relay Module provides reliable switching with a single changeover (SPDT) contact and a clear red LED status indicator. Designed for control cabinets and industrial applications, this compact module features Push-in Cage CLAMP® terminals for fast, tool-free wiring of solid or fine-stranded conductors from 0.34mm² to 2.5mm² (22AWG to 14AWG).

With a 24V AC coil and a contact rating of 16A at 250V AC, this relay handles substantial loads while maintaining dependable performance. The silver nickel contacts ensure durability and consistent conductivity over extended use.

The module mounts directly onto a DIN rail for straightforward installation and space-saving layout. Its dimensions (86mm x 54mm x 15mm) allow integration into standard control panels.

Key Features:

• SPDT contact configuration (1 changeover)
• 24V AC coil voltage
• 16A contact current
• Push-in Cage CLAMP® terminals
• Red LED status indicator
• DIN rail mounting
• Silver nickel contact material

Ideal for automation, building services, and machine control, this relay delivers robust switching in a compact, professional format.
