CLIFF Slim USB 2.0 Type A to B Feedthrough Connector, 3.2mm Holes
Compact USB 2.0 feedthrough connector for panel mounting. 3.2mm holes, gold contacts, 30VAC/1.5A rating.
The CLIFF Slim USB 2.0 Type A to B Feedthrough Connector is a versatile and durable solution for creating custom I/O configurations in wall plates, rack panels, and other panel-mounted applications. This feedthrough connector eliminates the need for soldering or punch terminations, as it utilises standard USB cables for seamless front and back connections.
With compact dimensions of 19 × 35.5mm and a narrow 17.15 × 22.86mm panel cut-out requirement, this connector is perfect for space-limited installations. The black plastic frame features a low rear profile, making it suitable for confined spaces.
Key Features
- Material: ABS insert, polyamide UL94 V2 plastic frame, PE + PVC inner overmouldings
- Contacts: Nickel-plated steel shell with gold-plated contacts for reliable performance
- Mounting: Front-mounted with various hole options (Ø3.2mm plain holes)
- Electrical Rating: 30VAC voltage rating, 1.5A maximum current
- Temperature Range: Operates from -20°C to 50°C
- USB Standard: USB 2.0 compliant
This connector is an excellent choice for anyone needing a robust and straightforward solution for USB Type A to Type B conversion in professional and DIY installations.
- Dispatched within 0-2 business days
- Delivery to United States: 3-5 business days*
- Free Shipping Included
- Wall plate installations
- Rack panel configurations
- Custom I/O panel setups
- Industrial control panels
- Material: ABS insert, polyamide UL94 V2 plastic frame
- Electrical Contacts: Nickel-plated steel shell, gold-plated contacts
- Mounting Options: Front-mount with Ø3.2mm plain holes
- Voltage Rating: 30VAC
- Current Rating: 1.5A max
- Operating Temperature: -20°C to 50°C
- USB Standard: USB 2.0
- Panel Cut-out Size: 17.15 × 22.86mm
- Overall Dimensions: 19 × 35.5mm
- Weight: 10g
