Harwin IC Socket DIL 32-Way, 0.6in/15.42mm, 12 Pack

The Harwin IC Socket provides a reliable and secure connection for 32-pin DIL (Dual In-Line) integrated circuits. Designed for professional applications, this socket features high-quality four-leaf beryllium copper contacts with 0.25µ thick gold plating, ensuring excellent electrical conductivity and corrosion resistance for long-term signal integrity.

Constructed with a robust glass-filled polyester body that is UL recognised, the socket offers durability and stability. The tin-lead plated brass pins facilitate reliable soldering to your PCB, while the 4.2mm low body profile makes it suitable for space-constrained designs. The socket is auto-insertable, streamlining high-volume assembly processes and improving production efficiency.

Supplied as a convenient 12-pack in complete tubes, these sockets are ideal for prototyping, batch production, or maintenance spares. The consistent 2.54mm pitch spacing and 15.24mm row pitch ensure compatibility with standard DIL IC footprints, providing a versatile solution for a wide range of electronic projects.

Key Features:

• Reliable four-leaf beryllium copper contacts for secure connections
• 0.25µ thick gold-plated contacts for optimal conductivity and durability
• Robust, UL-recognised glass-filled polyester body
• Low 4.2mm body height for compact designs
• Auto-insertable design for efficient assembly
• Tin-lead plated brass pins for reliable soldering
• Supplied in a convenient 12-pack
