JST PH Series 6-Way Top Entry Shrouded Header, 2.0mm Pitch
JST PH Series 6-way shrouded header, 2.0mm pitch, tin-plated brass contacts for reliable industrial connections.
The JST PH Series 6-Way Top Entry Shrouded Header is a high-quality, reliable 2.0mm pitch connector designed for wire-to-board applications. Its thin, low-profile design features a fully shrouded header with walls on all four sides to prevent improper connections and protect against flux and other contaminants. The connector offers a secure crimp-style disconnect and is compatible with KR, KRD, and CR insulation displacement connectors.
Features
- Compact Design: With a mounting height of 8.0mm and width of 4.5mm, this connector is ideal for space-constrained applications.
- Robust Construction: Made from brass with tin-plated contacts for reliable electrical performance and durability.
- Safety-Certified: UL, CSA, and TUV certified for safety and quality assurance.
- Wide Compatibility: Suitable for wire sizes from 32AWG to 24AWG.
Applications
These connectors are widely used in industrial settings where secure and stable connections are essential. Their shrouded design and high reliability make them ideal for applications requiring resistance to contaminants and secure mating.
Note: Due to high market demand, lead times for this product may vary and are subject to change. Discounts do not apply to this product.
Technical Specifications
- Dispatched within 0-2 business days
- Delivery to United States: 3-5 business days*
- Free Shipping Included
- Industrial equipment
- Electronics assembly
- Wire-to-board connections
- Control systems
- Ask Claude, ChatGPT or Perplexity to find the right tool, with our live prices and stock.
- Get a ready-made basket: one link puts everything in your basket here.
- You always pay securely here: your assistant never sees your card.
- Current Rating: 2A
- Voltage Rating: 100VAC/DC
- Temperature Range: -25°C to 85°C
- Wire Size Compatibility: 32AWG to 24AWG
- Number of Contacts: 6
- Contact Material: Brass
- Contact Plating: Tin Plated
- Certification: UL, CSA, TUV
- Pitch Spacing: 2mm
- Mounting Height: 8.0mm
- Width: 4.5mm
- Termination Type: Through Hole Straight
- Connector Series: PH
