KAUDAIR 120mm Cabinet Fan, 240V, 2m Lead, 50CFM

The KAUDAIR Cabinet Fan is an essential cooling solution designed specifically for data cabinets and enclosures that feature an industry-standard 120mm fan aperture. Engineered for efficiency and reliability, this fan delivers optimal airflow while operating at a remarkably low noise level, ensuring your equipment stays cool without disrupting the working environment.

Its construction includes a robust metal finger guard for safety and a high-quality rubber silicone gasket. This gasket is crucial as it sits between the fan unit and the metal cabinet, effectively lowering the noise floor and minimising vibrations for quieter operation. The fan has been acoustically tested, producing just 25/26dB(A), placing it at the very low end of the noise spectrum.

Performance is both effective and economical. With a power consumption of approximately 8W, it delivers a substantial air flow of 49/50 cubic feet per minute (CFM), making it highly efficient even if left running continuously 24/7. The unit comes complete with a pre-fitted 2-metre mains lead, terminated with a UK standard Type G plug for immediate and safe installation.

Safety and compliance are paramount. The fan is impedance protected and internally fused at 1A, meeting all current UK and EU safety standards. It features intelligent protection: if the fan rotor becomes locked by an external force while powered, the system will cut power to the motor to prevent coil overheating. Once the obstruction is cleared, the fan will automatically restart. All mains wiring is sheathed and securely fixed for complete safety during handling and installation.

The product is UKCA and CE marked and is TUV approved, guaranteeing quality and regulatory compliance. Its compact dimensions (120mm x 120mm x 38mm) ensure a perfect fit for standard cabinet openings, and installation is simplified with threaded M4 fixing slots—just use the provided 4mm screws without the need for separate nuts.
