KEMET T491 Surface Mount Tantalum Capacitor, 220µF, 10V, D Case

The KEMET T491 Series Surface Mount Tantalum Capacitor is an industrial-grade MnO2 standard tantalum capacitor engineered for automated surface mount processes and equipment. Combining solid tantalum technology with advanced materials, this capacitor meets or exceeds the requirements of EIA Standard 535BAAC, ensuring reliable performance across demanding applications.

Featuring a capacitance of 220µF with a ±10% tolerance and a 10V DC voltage rating, this component is suitable for decoupling and filtering. It incorporates symmetrical, compliant terminations to facilitate secure mounting. The epoxy encapsulation is halogen-free and compliant with UL94 V-0 flammability standards, offering enhanced safety for your electronic designs.

Key Specifications

• Capacitance: 220µF
• Voltage (DC): 10V
• Capacitor Case / Package: 2917 (7343 Metric)
• Capacitance Tolerance: ±10%
• Equivalent Series Resistance (ESR): 0.5 ohm
• Ripple Current: 548mA
• Operating Temperature Range: -55°C to 125°C
• Product Dimensions: 43mm x 33mm x 15mm
• Product Weight: 0.447g

Ideal for a wide range of applications, including DC/DC converters, portable electronics, telecommunications, and control units, the KEMET T491 capacitor provides a robust solution for power management, automotive, and consumer electronics industries.
