KINGSTATE - Micro Speaker, 8 Ohm - 20mm 0.3W

The KINGSTATE Micro Speaker is a compact and efficient audio component designed for a wide range of electronic applications. This dynamic micro speaker delivers clear, reliable sound output in a miniature form factor, making it an ideal choice for space-constrained designs. With an 8 ohm impedance and a rated power of 0.3W RMS, it offers a balanced performance for consumer electronics and portable devices.

The speaker features a resonant frequency of 560Hz and a wide frequency range from 0Hz to 7KHz, ensuring versatile audio reproduction. It provides a sound pressure level of 92dB at 0.3W/10cm, guaranteeing adequate volume levels for its size. The maximum input power of 0.5W ensures durability and headroom for demanding audio signals.

Key Features:

• Compact Design: With a diameter of just 20mm and a depth of 3.1mm, this speaker fits seamlessly into tight enclosures.
• Clear Audio: Frequency range from 0Hz to 7KHz and a high sensitivity of 92dB.
• Robust Performance: Operating temperature range from -20°C to 55°C makes it suitable for various environments.
• Easy Integration: Bare mount configuration allows for straightforward installation into your device.
• Dynamic Transducer: Provides responsive and accurate sound reproduction.

Whether you're developing test equipment, consumer gadgets, or portable audio devices, this micro speaker from KINGSTATE offers a dependable solution. Its precise engineering and high-quality construction ensure long-lasting performance and consistent audio output. Choose the KINGSTATE Micro Speaker for your next project to benefit from reliable sound in a compact package.

Applications: This speaker is suitable for a variety of uses, including test equipment, consumer electronics, portable devices, and any other application requiring a small, high-quality audio output.

Variant Details

• Size: 20mm 0.3W
