MEAN WELL Isolated DIN Rail DC/DC Converter 24V 2.5A 60W
MEAN WELL 60W isolated DIN rail DC/DC converter. 24V 2.5A output, 9-36VDC input, 4kV isolation. Ideal for industrial control.
The MEAN WELL Isolated DIN Rail DC/DC Converter delivers a reliable 60W power output with a 24V DC voltage and 2.5A rated current. Weighing just 209 grams and designed for easy installation, this ultra-slim converter features a 4:1 ultra-wide input voltage range from 9 to 36VDC, making it highly adaptable for various power environments. It provides robust 4kVdc I/O isolation and an adjustable output voltage of ±10%, ensuring precise power delivery.
This converter is equipped with comprehensive protective functions, including short circuit, overvoltage, overload, input reverse polarity, and input under voltage protection. It requires no minimum load and operates efficiently at 91% typical efficiency, cooled by free air convection. The unit performs reliably across a wide working temperature range from -40°C to +85°C. It also meets stringent safety standards, holding approvals from IEC 62368-1, UL 62368-1, AS/NZS 62368-1, and EAC TP TC 004.
Key Features
- 60W output power with 24V DC output
- 4:1 ultra-wide input voltage (9 to 36VDC)
- 4kVdc I/O isolation voltage
- Adjustable output voltage (±10%)
- Ultra-slim design for space-saving installation
- Full protective functions (short circuit, overvoltage, overload, reverse polarity, under voltage)
- Typical efficiency of 91%
- Free air convection cooling
- Wide operating temperature range (-40°C to +85°C)
- No minimum load required
Ideal for demanding environments, this converter is perfectly suited for DC buck/boost regulation, increasing system insulation levels, and compensating for voltage drops along cables.
