MULLER BW 40 Panel Mount Hours Counter, 110V AC, 7-Digit

The MULLER BW 40 Series Panel Mount Hours Counter is a non-resettable, 7-digit motor-driven elapsed hour counter designed for reliable and accurate tracking of operating hours. Housed in a durable Noryl and Makrolon panel mounting case, this counter is built to withstand demanding industrial environments.

With a resolution of 0.01 hours for AC types, this 110V AC unit provides precise measurement for a wide range of applications. The clearly visible display features decimal digits in red for easy reading of fractions, while other digits are presented in white for optimal contrast. The frequency of DC types is controlled by a quartz crystal, ensuring stable and accurate timing.

Key Features:

• Non-resettable 7-digit motor-driven counter for tamper-proof tracking
• Housed in durable Noryl and Makrolon panel mounting case
• Resolution: 0.01 hours (AC types)
• Red decimal digits and white non-decimal digits for clear reading
• Supplied with panel mounting bracket for easy installation
• Connection via screw terminals or 6.35mm (0.25”) fast-on terminals

Specifications:

• Supply Voltage: 93.5V AC to 126.5V AC (110V AC nominal)
• Maximum Time Range: 99999 hours
• Panel Cutout: Compatible with standard panel mounting (details not specified)
• Dimensions: 43mm height x 33mm width x 15mm depth
• Weight: 50 grams

This panel mount hours counter is the ideal solution for monitoring equipment runtime, maintenance intervals, and machine usage. Its robust construction and precise timekeeping make it a dependable choice for industrial, commercial, and agricultural applications.
