MULTICOMP 37-Pin IDC D-Sub Plug, Steel Body, 1.5A
Industrial-grade 37-pin D-Sub plug with tin-gold contacts & steel body for reliable connectivity in harsh environments.
The MULTICOMP 37-Pin IDC D-Sub Plug is a high-quality connector designed for reliable performance in demanding environments. Featuring a robust stamped tin-plated steel shell and copper alloy contacts, this connector ensures durability and excellent electrical conductivity.
The contacts are tin-plated (1.5-micron thickness) with an additional 0.2-micron gold plating, enhancing corrosion resistance and signal integrity. The glass-filled polyester insulator provides superior insulation resistance (5000MΩ) and thermal stability (-55°C to +125°C).
Key Features
- Contact resistance: <10mΩ
- 1.5A current rating
- Available with or without 4-40 UNC threads
- Compatible with standard back shells
- IDC (Insulation Displacement Connector) termination
Applications
Ideal for:
- Communications & Networking
- Computers & Computer Peripherals
- Industrial Equipment
The MULTICOMP MH105 Series connector is a dependable choice for secure and long-lasting connections in professional and industrial settings.
After bigger quantities? Need extra quantities? Get in touch and we'll organise it for you.
- Dispatched within 0-2 business days
- Delivery to United States: 3-5 business days*
- Free Shipping Included
- Communications & Networking
- Computers & Peripherals
- Industrial Equipment
- Contact Material: Copper Alloy
- Contact Plating: Tin (1.5µm) + Gold (0.2µm)
- Connector Body Material: Steel
- Insulator Material: Glass-Filled Polyester
- D-Sub Shell Size: DC
- Contact Termination: IDC
- Number of Contacts: 37
- Current Rating: 1.5A
- Insulation Resistance: 5000MΩ
- Contact Resistance: <10mΩ
- Operating Temperature: -55°C to +125°C
- Shell Plating: Tin & Dimple
- Mounting Type: Cable Mount
- Optional Threading: 4-40 UNC (available on request)
- Weight (approx.): 10g
