NEUTRIK NBB75FG BNC Socket to BNC Panel Adaptor, 75 Ohm
Professional NEUTRIK BNC socket adaptor (75 ohm) for HD/SDI video & RF communications. Gold-plated brass contacts.
The NEUTRIK NBB75FG is a premium quality feedthrough grounded BNC jack designed for panel mounting applications. Engineered with a true 75 ohm design, it ensures optimal performance for serial and digital (HD) signals, making it perfect for professional audio-visual setups.
Featuring a machined brass connector body with gold-plated cage-type centre contacts, this adaptor offers extremely rugged construction and non-abrasive connectivity for long-term reliability. The PTFE insert and polyacetal (POM) shell further enhance durability and signal integrity.
Key Features
- True 75 ohm impedance design meets stringent HD requirements
- Supports multiple signal types including HD, SDI, video, AES/EBU, composite, YUV, RGB, RGBH, and RGBHV
- Rugged brass construction with gold-plated contacts for superior conductivity
- Bayonet locking mechanism ensures secure connections
- Rated for more than 1000 mating cycles
- Front mounting design for easy installation
- Wide operating temperature range: -30°C to +85°C
- Low rated voltage (<50V) and high dielectric strength (1.5KVDC) for safety and performance
Ideal for RF communications and professional AV applications, the NEUTRIK NBB75FG delivers reliable, high-quality signal transmission in demanding environments.
After bigger quantities? Need extra quantities? Get in touch and we'll organise it for you.
- Dispatched within 0-2 business days
- Delivery to United States: 3-5 business days*
- Free Shipping Included
- * **RF communications**
- * **Professional AV equipment**
- * **HD/SDI video systems**
- * **Broadcast equipment**
- * **Impedance:** 75 ohm
- * **Connector Type:** BNC Coaxial
- * **Material:** Brass with gold-plated contacts, PTFE insert, polyacetal (POM) shell
- * **Mounting Type:** Front mounting
- * **Locking Mechanism:** Bayonet
- * **Mating Cycles:** >1000
- * **Temperature Range:** -30°C to +85°C
- * **Rated Voltage:** <50V
- * **Dielectric Strength:** 1.5KVDC
- * **Adapter Body Style:** Straight bulkhead adapter
- * **Convert From/To Coax Type:** BNC
- * **Convert From/To Gender:** Jack to Jack
- * **Weight:** 20g
