Neutrik XLR Panel Plug, 3-Pin, Horizontal PCB Mount
Neutrik XLR panel plug with gold-plated contacts, steel locking, and UL94V-0 flame-resistant housing for professional audio.
The Neutrik NC3MAH is a high-quality 3-pin XLR audio plug designed for professional audio applications. Featuring gold-plated brass contacts, this connector ensures superior signal integrity and durable performance. The 0.2µm AuCo over 2µm NiP15-plated contacts enhance conductivity and resist corrosion, while the polyamide (PA 6.6 30% GR) insert provides heat resistance and mechanical stability.
Constructed with a steel CK67 locking element and black plastic flange, this XLR plug guarantees a secure and stable connection. Its round plastic body is designed for PCB mount panel installation, making it an excellent choice for audio equipment. The male XLR receptacle ensures compatibility with standard XLR cables, while the separate ground contact improves noise immunity by connecting to the mating connector shell and front panel.
Key Features:
- Gold-plated contact terminals for reliable signal transmission.
- Durable steel latch lock ensures a secure connection.
- Polyamide insert for enhanced mechanical strength.
- UL94V-0 flame-rated housing for safety compliance.
- Horizontal PCB mounting for easy installation in rack and panel applications.
Technical Specifications
- Voltage Rating: 50V
- Current Rating: 6A
- Contact Resistance: ≤5mΩ
- Insulation Resistance: >2GΩ (Initial), >1GΩ (after damp heat test)
- Connector Type: Male Plug
- Mounting Style: Horizontal PCB Mount
- Dispatched within 0-2 business days
- Delivery to United States: 3-5 business days*
- Free Shipping Included
- Professional audio equipment
- Studio recording setups
- Live sound reinforcement
- Broadcast installations
- Material: Brass contacts with 0.2µm AuCo over 2µm NiP15 plating
- Insert Material: Polyamide (PA 6.6 30% GR)
- Locking Mechanism: Steel CK67
- Flange Material: Black Plastic
- Voltage Rating: 50V
- Current Rating: 6A
- Contact Resistance: ≤5mΩ
- Insulation Resistance: >2GΩ (Initial), >1GΩ (after damp heat test)
- Housing Rating: UL94V-0
- Mounting Style: Horizontal PCB
