ONSEMI 74HC14 Hex Inverter Logic IC, 14-Pin SOIC

The ONSEMI 74HC14 Hex Inverter Logic IC features a Schmitt trigger input, making it highly effective for squaring up slow input rise and fall times. Designed with a pin-out identical to the LS14, LS04, and HC04, this versatile device offers seamless integration into existing and new circuit designs.

Its standard CMOS output compatibility, along with LSTTL output compatibility when used with pull-up resistors, provides flexible interfacing options for a wide range of logic families. The inherent hysteresis voltage of the Schmitt trigger ensures reliable performance, making this logic IC particularly suitable for use in noisy environments where signal integrity is critical.

Operating within a supply voltage range of 2V to 6V, the inverter delivers a robust output drive capability of up to 10 LSTTL loads. It also features a low input current of just 1mA and a chip complexity equivalent to 60 FETs or 15 equivalent gates. Housed in a compact 14-pin SOIC package, this Pb-free device is engineered to withstand demanding conditions with a broad operating temperature range from -55°C to 125°C.
