Stereo Amplifier Module 2x 1.5W

This stereo amplifier module delivers a total output of 2 x 1.5W, providing a simple and universal audio solution for a wide range of DIY projects and electronic applications. Operating on a versatile supply voltage of 3-10Vdc, this compact module is suitable for battery-powered devices as well as low-voltage power supplies.

Designed to drive loudspeakers with impedances between 8-32Ω, the amplifier offers an input sensitivity of less than 100mV, making it compatible with line-level audio sources such as MP3 players, smartphones, or audio breakout boards. With a frequency response spanning 20-20000Hz, it faithfully reproduces the full audible spectrum, ensuring clear and balanced sound.

Specifications

• Output Power: 2 x 1.5W
• Operating Voltage: 3-10Vdc
• Loudspeaker Impedance: 8-32Ω
• Input Sensitivity: < 100mV
• Frequency Response: 20-20000Hz
• Dimensions: 60 x 45 x 20mm (module)

Weighing only 106 grams and with compact dimensions of 43 x 33 x 15mm (device), this module is ideal for integration into portable speakers, educational kits, and custom electronics, offering a straightforward and reliable amplification stage for hobbyists and engineers alike.
