Amphenol 44-Pin Hi-Density D-Sub Socket, HD Series
Industrial-grade 44-pin D-Sub socket with gold-plated contacts, steel shell, and high-density design for demanding applications.
The Amphenol 44-Pin Hi-Density D-Sub Socket is a premium connector that extends Amphenol's renowned D-Sub product line. Engineered to provide superior signal density, its reduced contact spacing significantly outperforms conventional D-Sub connectors, making it ideal for high-performance applications where space is at a premium.
Constructed from steel with nickel plating, the socket ensures durability and resistance to corrosion. The glass-filled thermoplastic insulator (meeting UL 94V-0 standards) guarantees excellent electrical insulation and thermal stability. Internally, the copper alloy contacts feature selective gold plating, ensuring minimal signal loss and high conductivity.
With a current rating of 3A and a voltage rating of 600V AC/rms 50Hz, this connector meets stringent industrial requirements. It also boasts a withstanding voltage of 1000V AC/rms 50Hz for one minute and an impressive insulation resistance of 5000MR. The socket performs reliably across a wide operating temperature range of -55°C to +125°C.
Key Features:
- High-Density Design: Ideal for applications requiring compact, high-signal-density connections.
- Premium Materials: Steel shell with nickel plating and gold-plated copper alloy contacts.
- Termination: Solder-cup termination ensures secure and durable cable connections.
- Industry-Standard Compatibility: Fits DB-sized connectors for seamless integration.
Applications:
- Industrial machinery and automation systems.
- Telecommunications and networking equipment.
- High-density I/O connections where standard D-Subs fall short.
- Industrial Equipment
- Telecom Devices
- High-Density I/O Applications
- Shell Material: Steel with Nickel Plating
- Insulator Material: Glass-filled Thermoplastic (UL 94V-0)
- Contacts: Copper Alloy with Gold Plating
- Current Rating: 3A
- Voltage Rating: 600V AC/rms 50Hz
- Withstanding Voltage: 1000V AC/rms 50Hz (1 min)
- Insulation Resistance: 5000MR
- Contact Resistance: 10mR Max
- Operating Temperature: -55°C to +125°C
- Connector Type: High-Density D-Sub (HD Series)
- Gender: Receptacle
- No. of Contacts: 44
- Shell Size: DB
- Termination: Solder Cup
- Mounting Type: Cable Mount
