HYLEC 4 Pole DC Isolator Switch - 16A

The HYLEC 4 Pole DC Isolator Switch is engineered to provide reliable and safe isolation for direct current electrical systems. Designed with a highly visible, robust housing, this switch ensures easy identification and enhanced durability in demanding environments. The enclosure is crafted from polycarbonate UL94V-0 flame retardant material, offering superior protection against fire hazards.

Safety and reliability are paramount, which is why this isolator switch features silver plated alloy contacts that guarantee high conductivity and long-term performance. It includes a 4-pole earth terminal for comprehensive grounding and safety compliance. For secure maintenance and operation, the unit is equipped with captive retained cover screws and can be padlocked to prevent unauthorised access (padlock not included).

With an IP66 rating, this switch is fully protected against dust and powerful water jets, making it suitable for both indoor and outdoor installations. It boasts impressive electrical specifications, including a rated insulation voltage of 1500V AC and a rated impulse withstand voltage of 8000V. The switch also offers robust short-circuit protection with a rated conditional short-circuit current of 5000A and accommodates a maximum fuse size of 40A. Designed for straightforward installation, it utilises a screw fixing mount for secure attachment. This isolator switch is an essential component for any DC electrical setup requiring dependable isolation.

Variant Details

• Size: 16A
