HYLEC Ceramic High-Temperature Terminal Block, 4-Pole, 12-32AWG, 450V AC, 41A
Robust HYLEC ceramic terminal block for high-temp applications. 4-pole, 32A, 450V AC, 12-32AWG, ideal for industrial use.
The HYLEC Ceramic High-Temperature Terminal Block (DESTB-0254) is a robust 4-pole terminal block made from steatite ceramic, designed for high-temperature and high-voltage applications. Ideal for industrial and electrical projects requiring reliable performance in demanding conditions.
Specially engineered to withstand extreme environments, this terminal block features chemical resistance, non-flammability, and corrosion resistance, ensuring long-term durability and safety. Its dimensional stability remains intact even at temperatures up to 800°C, making it suitable for high-heat applications.
Key Specifications
- Material: Steatite ceramic
- Temperature Rating: -40°C to +300-350°C
- Max Voltage: 450V AC (750V peak)
- Current Rating: 32A at 450V, 41A peak
- Conductor Size: 12-32AWG (1.5-6mm²)
- Pitch Spacing: 11mm
- Mounting Type: Surface mount
- Dimensions: 43x18x15.6mm
This terminal block is perfect for use in electrical panels, industrial machinery, HVAC systems, and high-temperature environments, providing secure and stable connections.
- Shipped within 0-2 business days
- Shipping to United States: 3-5 business days*
- Free Shipping Included
- Industrial electrical panels
- HVAC systems
- High-temperature machinery
- Power distribution units
- Material: Steatite ceramic
- Chemical Resistance: Yes
- Non-Flammability: Yes
- Heat Resistance: Yes (up to 350°C continuous, 800°C stability)
- Corrosion Resistance: Yes
- Temperature Rating: -40°C to +300-350°C
- Max Voltage: 750V
- Conductor Size: 1.5-6mm² (12-32AWG)
- Current Rating: 32A at 450V AC
- Number of Contacts: 4
- Pitch Spacing: 11mm
- Mounting: Surface mount
- Dimensions: 43x18x15.6mm
- Weight: 30g
Always follow local regulations and product guidance.
