PANASONIC - Electrolytic Capacitor, 1000 µF, ± 20%, Through Hole, Polar - 63

The PANASONIC NHG-A Series is a high-quality range of electrolytic capacitors designed for robust performance in a wide variety of electronic circuits. These through-hole, polarised capacitors are engineered to offer reliable capacitance in demanding environments, providing stable power filtering, smoothing, and energy storage where it is needed most.

Featuring an aluminium electrolytic construction, these components are built to last. They are characterised by their cylindrical body with clearly marked polarity indicators, ensuring correct and safe installation on printed circuit boards (PCBs). The through-hole design facilitates strong mechanical bonds and reliable solder joints, making them a staple in both prototyping and production-scale electronics.

A key specification of this specific model is its 1000 µF capacitance and a 16V DC voltage rating, making it suitable for intermediate power applications. With a generous ±20% tolerance, it offers flexibility for circuits where exact capacitance values are not critically precise. The components are rated for an extensive operating temperature range from -55°C to +105°C, ensuring dependable operation in both consumer and industrial settings, even under thermal stress.

Ideal for use in power supply units, audio amplifiers, and various control boards, this capacitor helps to reduce voltage ripple and provide temporary power backup. Its 5mm lead spacing is a standard dimension that matches common PCB layouts, simplifying the design and assembly process. Manufactured by Panasonic, a trusted leader in electronic components, you are assured of consistent quality and performance that meets rigorous industry standards.

Variant Details

• Size: 63
