PRO ELEC 32A Single Pole Type B MCB, 10kA, 230V
PRO ELEC 32A single pole MCB, 10kA breaking capacity for reliable circuit protection in 230V systems.
The PRO ELEC 32A Single Pole Type B MCB is a high-quality miniature circuit breaker designed for reliable electrical protection in residential and light commercial applications. Built to IEC60898 and EN60898 standards, this 1-pole MCB ensures safety and compliance with stringent electrical regulations.
With a breaking capacity of 10kA, it provides robust overcurrent and short-circuit protection. The lug-type terminals accommodate cables up to 25mm², making it versatile for various installation requirements. Compact and efficient, it features a slim design with a module width of just 17.6mm, allowing for space-saving installations within consumer units.
Key Features
- Rated Current: 32A
- Rated Voltage: 230V AC
- Breaking Capacity: 10kA
- Terminal Type: Lug type
- Terminal Capacity: Supports cables up to 25mm²
- Standards Compliance: IEC60898, EN60898
- Dimensions (H x W x D): 83mm x 28mm x 66mm
This MCB is an essential component for ensuring electrical safety, protecting circuits from overloads and faults. Its durable construction and reliable performance make it ideal for a wide range of applications.
- Shipped within 0-2 business days
- Shipping to United States: 3-5 business days*
- Free Shipping Included
- Residential electrical installations
- Light commercial electrical systems
- Consumer unit protection
- Circuit protection for appliances
- Rated Voltage (Un): 230V AC
- Breaking Capacity: 10kA
- Number of Poles: 1
- Terminal Type: Lug type
- Terminal Capacity: Up to 25mm² cable
- Width: 17.6mm per module
- Compliance Standards: IEC60898, EN60898
- Dimensions (H x W x D): 83mm x 28mm x 66mm
- Current Rating: 32A
- Voltage Rating: 230V AC
Always follow local regulations and product guidance.
