Timco TX Countersunk Concrete Screws, 7.5x60mm, Zinc & Yellow (6 Pieces)

The Timco TX Concrete Screws provide a rapid and effective light-duty anchoring system for concrete, brick, stone, concrete block, and wood. Designed to replace traditional masonry fixings, these screws offer superior performance with reduced driver wear and improved security in diverse materials.

Key features include a TX30 drive recess to prevent camming-out, serrated V-threads for optimal grip, and a high-low thread profile on the first 30mm to ease insertion and reduce torque. The screws are zinc-plated and yellow passivated, ensuring high corrosion resistance and durability in harsh conditions.

The flat countersunk head features five locking ribs for enhanced stability, making them ideal for fixing window and door frames. These all-steel, non-flammable fixings comply with BS 7671 18th edition, ensuring fire-resistant support for wiring systems.

Technical Specifications

• Thread Diameter: 7.5mm
• Length: 60mm
• Head Type: Flat countersunk with ribs
• Drive Type: TX Drive
• Finish: Zinc & Yellow Passivated
• Drill Hole Dia: 6.0mm
• Fixture Hole Dia: 8.0mm
• Min Embedment Depth: 35mm
• Material: Steel (non-flammable)
• Compliance: BS 7671 18th Edition

Perfect for fast, reliable anchoring in masonry and wood, these screws eliminate the need for separate plugs and anchors, streamlining installation while maintaining structural integrity.
