AMPOHM DC Film Capacitor 2.2µF 630V PP FP-CA-AU Audio Series

The AMPOHM FP-CA-AU Audio Series DC Film Capacitor is specially designed for high-performance audio systems. Featuring a metallised polypropylene (PP) dielectric, this component ensures exceptional audio clarity and reliability for demanding applications.

Each capacitor is meticulously hand-wound, with insulated tinned copper leads that are hand-soldered before assembly. The unit is housed in a flame-retardant plastic case and resin sealed, making it hermetically sealed. Furthermore, these capacitors are individually hand tested and feature self-healing properties, ensuring long-lasting performance and safety.

This robust construction results in the capacitor having low Equivalent Series Resistance (ESR) and low inductance. It also possesses high stability with respect to both temperature and frequency variations, which is critical for premium audio setups.

Key Specifications:

• Capacitance: 2.2µF
• Voltage Rating: 630V DC
• Tolerance: ± 5%
• Mounting: Through Hole

With an operating temperature range of -40°C to 85°C, compact dimensions of 43 mm height, 33 mm width, and 15 mm depth, and a weight of 31 grams, it is ideally suited for seamless integration into your audio projects.
