BLOCK 1VA Safety Transformer, 2 x 6V, PCB Mount

The BLOCK 1VA Safety Transformer is a compact and reliable encapsulated unit designed for the safe electrical isolation of input and output circuits, enabling the creation of SELV (Safety Extra-Low Voltage) and PELV (Protective Extra-Low Voltage) systems. Its construction utilises advanced XtraDenseFill resin encapsulation, which provides permanent corrosion protection, a high insulation value, and maximum electrical reliability. This robust potting, along with self-extinguishing hood material, ensures the transformer is suited for demanding industrial environments and power management applications.

Engineered for high performance, this transformer is inherently short-circuit proof and operates efficiently even at high ambient temperatures. Its dual primary and dual secondary windings offer exceptional flexibility, allowing for series or parallel connections on both the input and output sides to suit various voltage requirements. This feature makes it a versatile component for diverse circuit designs.

With a compact footprint, it delivers a reliable 1VA power rating in a minimal size, making it ideal for space-constrained PCB (printed circuit board) layouts. The through-hole mounting provides a secure and stable physical connection for permanent installations.

Key Specifications & Features

• Safety Standard: Functions as a safety isolating transformer for SELV/PELV circuits.
• Encapsulation: XtraDenseFill resin ensures durability, moisture resistance, and high electrical insulation.
• Construction: Features self-extinguishing potting and hood material for enhanced fire safety.
• Reliability: Designed for high ambient temperatures and is inherently short-circuit proof.
• Flexibility: Dual input voltage (2 x 115V) and dual output voltage (2 x 6V) for series or parallel connection.
• Mounting: Through-hole design for secure PCB mounting.

This BLOC
