CAMDENBOSS 12-Way Pluggable Terminal Strip, 450V AC, 12 AWG
Durable CAMDENBOSS terminal strip with 12 contacts, 450V AC, and self-extinguishing PA6 material.
The CAMDENBOSS 12-Way Pluggable Terminal Strip is a highly reliable and durable solution for electrical connections. Moulded in natural PA6, it is self-extinguishing and meets the UL94-V2 standard, ensuring safety in high-temperature environments. Additionally, it passes the 960°C glow-wire test according to EN 60695-2-11.
This terminal strip can be easily cut to size, providing flexibility for custom installations. It is designed for maximum efficiency and convenience, with 12 contacts arranged at an 8mm pitch. The pluggable connector type facilitates quick and easy installation and removal.
Key Features:
- Voltage Rating: 450V AC
- Cable Acceptance: 4mm² / 12 AWG
- Maximum Current: 17.5A
- Terminal Screws: M3
- Dimensions (LxWxH): 94x16x15.4mm
- Fixing Hole Diameter: 2.75mm
This terminal strip is perfect for applications requiring secure and robust electrical connections, including industrial control panels, automation systems, and electrical distribution setups.
- Industrial control panels
- Automation systems
- Electrical distribution setups
- Secure and robust electrical connections
- Material: Natural PA6 (self-extinguishing to UL94-V2)
- Test Standard: Passes 960°C glow-wire test (EN 60695-2-11)
- Voltage Rating: 450V AC
- Cable Acceptance: 4mm² / 12 AWG
- Maximum Current: 17.5A
- Terminal Screws: M3
- Pitch / UL Rating: 8mm / 6A
- Dimensions: 94mm x 16mm x 15.4mm
- Fixing Hole Diameter: 2.75mm
- Product Range: CTSN
- No. of Contacts: 12
- Connector Type: Pluggable Terminal Block
- Contact Plating: Zinc Plated
- Contact Material: Brass
Always follow local regulations and product guidance.
