CLIFF 6.35mm Vertical PCB Mount Stereo Jack Socket, Switched
Vertical PCB mount stereo jack socket with 2 switching contacts, 5A rating & high durability. Ideal for audio & electronic circuits.
The CLIFF 6.35mm (1/4") Vertical PCB Mount Stereo Jack Socket provides a robust and reliable connection solution for audio applications. With its compact vertical mounting design and 24mm stand-off, it enables high packing density, making it ideal for space-constrained PCB layouts. The snap-in mounting system facilitates easy pre-assembly and wave soldering, ensuring efficient manufacturing processes.
This socket features 2 switching contacts and 1 breaking contact, offering versatile functionality for stereo audio connections. The nylon (polyamide) body ensures durability and supports auto-insertion, enhancing production efficiency.
Key Features
- Compact vertical PCB mounting with 24mm stand-off for high packing density
- Snap-in PCB mounting simplifies pre-assembly and wave soldering
- Auto-insertion-compatible body design
- High-voltage resistance: Withstands 2000V DC
- High current capacity: Up to 5A
- Reliable switching action: 10,000+ operations lifespan
- Low contact resistance: <50mΩ nominal
- Wide temperature tolerance: -10°C to +70°C
Ideal for audio equipment, mixers, amplifiers, and professional sound systems, this jack socket ensures secure and stable connections in various embedded applications.
- Audio equipment
- Mixers and amplifiers
- Professional sound systems
- PCB-based electronics
- Ask Claude, ChatGPT or Perplexity to find the right tool, with our live prices and stock.
- Get a ready-made basket: one link puts everything in your basket here.
- You always pay securely here: your assistant never sees your card.
- Withstand Voltage: 2000V DC
- Current Rating: 5A
- Temperature Range: -10°C to +70°C
- Operational Life: 10,000+ insertions
- Contact Resistance: <50mΩ
- Contacts: 3 (2 switching, 1 breaking)
- Gender: Jack
- Pin Diameter: 6.35mm (1/4")
- Mounting Type: PCB Mount
- Body Material: Nylon (Polyamide)
- Product Range: S1VS
