Cliff PD USB C Socket to USB C Right Angle Plug Feedthrough Connector, Black

The Cliff PD USB C Socket to USB C Right Angle Plug Feedthrough Connector is a highly practical and space-saving connectivity solution, designed to integrate seamlessly into panels and enclosures. It fits a standard XLR Ø24mm cutout and features a low rear profile, making it ideal for applications where space behind the panel is limited. This versatile connector can be mounted from either the front or rear without the need for soldering or punch termination, allowing for simple, tool-free installation using standard USB C cables.

Engineered for modern power needs, this feedthrough connector is fully compatible with Power Delivery (PD) 3.1 via its USB Type C interface. It supports a maximum current rating of 3A, ensuring reliable power transfer for a wide range of devices, from smartphones and tablets to laptops and other USB-C powered equipment. The 90° or right-angle rear cable entry helps to manage cable routing neatly, reducing strain on the connection and saving valuable space within the enclosure.

Constructed with a durable black plastic frame and featuring counter-sunk (CSK) mounting holes, this connector offers a professional and secure fit. Its design facilitates a clean pass-through connection, converting from a USB Type C receptacle on the panel face to a USB Type C plug on the rear. This makes it perfect for creating permanent, integrated USB charging or data ports in custom installations, from professional AV racks and flight cases to vehicle dashboards and industrial control panels.

Key Specifications

• Cutout Size: Fits standard XLR Ø24mm hole
• Mounting: Front or rear panel mountable
• Connection: Converts USB Type C Receptacle to USB Type C Plug
• USB Standard: USB Power Delivery (PD) 3.1 compatible
• Max Current: 3A
• Cable Entry: 90° right-angle rear entry
• Termination: No soldering required; uses standard cables
