DURAKOOL Automotive Relay SPDT, 24V DC, 60A

The DURAKOOL DG85B Series Automotive Relay is a robust, general-purpose relay designed for demanding applications in vehicles and industrial settings. Featuring SPDT (Single Pole Double Throw) contacts with a 1 C/O (changeover) arrangement, it provides versatile switching capabilities for remote control circuits. Its silver nickel (AgNi0.15) contacts ensure reliable performance and longevity, even under high electrical loads.

This relay is engineered to handle high inrush currents, making it ideal for controlling DC motors, lighting systems, and other inductive loads commonly found in automotive environments. With a high continuous DC current capacity of 100A and a rated contact current of 60A, it delivers exceptional power handling in a compact, industry-standard footprint. The panel-mount design with quick-connect flat blade terminals allows for straightforward and secure installation.

Key Features & Specifications

• High Inrush Capability: Handles sudden current surges with ease.
• IP54 Protection: Rated against dust ingress and water splashes for increased durability in harsh conditions.
• Wide Voltage Range: Coil voltage of 24V DC, with a maximum allowable voltage of 39.1V DC and a minimum must-release voltage of 2.4V DC.
• Low Contact Resistance: Maximum initial contact resistance of less than 100mΩ, ensuring efficient power transfer.
• Excellent Insulation: High insulation resistance of 100MΩ at 500V DC for safe and reliable operation.

Commonly used throughout modern vehicles—with a typical car containing twenty or more—these relays are essential components in engine management, lighting, screen wiping, steering, and electric mirror systems. Their robust construction also makes them suitable for use in electric vehicles and various industrial control applications.
