Finder 55 Series Power Relay, 4PDT, 24V DC, 7A

This Finder 55 Series Power Relay is a high-quality plug-in mount general-purpose relay, designed for reliable switching in a wide range of industrial and commercial applications. With a 4PDT (4CO) contact configuration and a 24V DC coil, this relay is capable of switching currents up to 7A at 250V AC, making it suitable for demanding control circuits.

The relay features cadmium-free standard AgNi contacts, ensuring environmentally friendly operation without compromising on performance. A lockable test button with an LED and mechanical indicator simplifies installation and troubleshooting, allowing you to manually operate the relay and verify its status with ease. The integrated diode (polarity positive to pin A1/13) provides coil surge suppression, protecting your circuit from voltage spikes.

Designed for use with 94-series sockets, this relay offers a secure and convenient plug-in mounting solution. Its compact dimensions (22mm width, 33mm height) and quick connect terminals make it easy to integrate into your existing setup. The relay operates reliably across a wide temperature range from -40°C to 85°C, ensuring consistent performance even in harsh environments.

Specifications

• Contact Configuration: 4PDT (4CO)
• Coil Voltage: 24V DC
• Contact Current: 7A
• Contact Voltage: 250V AC
• Contact Material: Silver Nickel (AgNi), cadmium-free
• Coil Resistance: 600 ohms
• Relay Mounting: Socket mount (plug-in)
• Terminals: Quick connect
• Suitable Socket Series: 94-series
• Operating Temperature: -40°C to +85°C
• Indicators: LED and mechanical
• Test Button: Lockable
• Coil Suppression: Diode (polarity positive to pin A1/13)
• Dimensions (W x H x D): 22mm x 33mm x 2mm (sockets add depth)
• Weight: 37g

This relay is ideal for use in automation,,
