Finder UK DIN Rail Safety Relay DPST-NO SPST-NC 24V DC 10A

The Finder UK 7S Series Safety Relay is a modular relay featuring forcibly guided contacts, designed specifically for safety applications. Compliant with EN 61810-3 for class A forcibly guided contact relays, it ensures reliable operation in critical environments.

This relay has been evaluated for SIL 2 according to EN 61508 and is suitable for functional safety applications up to SIL 2 according to EN 62061, as well as up to PL d according to IEC 13849-1. It provides functional reliability in machinery and plant engineering, making it a robust choice for industrial safety systems.

Equipped with a DC coil and cadmium-free contacts, this relay features visual indication of the coil status via an integrated LED. It is designed for 35mm DIN rail mounting (EN 60715) and features screw terminals for secure connections. The relay has a contact configuration of 2 NO + 1 NC (DPST-NO + SPST-NC) and operates on a 24V DC supply with an operating range of 16.8 to 30V.

With a rated switching voltage of 250V AC and a contact current of 10A, it delivers consistent performance. The AgNi + Au contact material ensures excellent conductivity and longevity, supported by a mechanical life of 10 · 10⁶ operations. It boasts an IP20 rating and operates reliably in ambient temperatures ranging from -40 to +70°C. Compact dimensions of 43mm in height, 33mm in width, and 15mm in depth allow for space-efficient installation within control panels.
