Honeywell 14CE2-3 Roller Plunger Limit Switch, 22.5N, 250V, 5A

The Honeywell 14CE2-3 is a compact precision limit switch from the 14CE series, designed for reliable performance in demanding industrial environments. Featuring a 1NO/1NC SPDT snap-action mechanism and a top roller plunger parallel actuator, this switch ensures precise and consistent operation.

Engineered with a rugged die-cast zinc housing, the switch provides excellent durability in harsh factory floor conditions. The fluorocarbon diaphragm sealing meets NEMA 1, 2 and IP65 requirements, offering reliable protection against dust and water ingress. Additionally, the cable and basic switch terminals are encapsulated in an epoxy compound, delivering superior resistance in challenging environments.

This switch is versatile and suitable for a wide range of applications, including processing equipment, textile machinery, machine tools, farm machinery, and printing trade machinery. Its compact construction minimizes space usage on equipment, while the gang mounting capability allows for multi-plunger limit switch configurations. Simple two-screw mounting simplifies installation, and low temperature variants ensure functionality over a wide temperature range.

Important: This product is not intended for use as a safety or emergency stop device, or in any application where failure could result in personal injury.

Specifications:

• Actuator: Roller Plunger
• Contact Configuration: 1NO/1NC SPDT
• Contact Current AC Max: 5A
• Contact Voltage AC Max: 250V
• Operating Force Max: 22.5N
• Product Range: 14CE Series
• Housing Material: Die-cast zinc
• Sealing: Fluorocarbon diaphragm (IP65, NEMA 1 & 2)
• Cable Length: 3m
• Dimensions (HxWxD): 43 x 33 x 15 mm
