IMO 11-Pin Plug-In Power Relay with Push Button & Flag 12V DC

The IMO 11-Pin Plug-In Power Relay with Push Button & Flag is a versatile and reliable component designed for precise electrical control in 12V DC systems. Part of the trusted RSE Series, it features a clear manual override in the form of a push button with an integrated status flag, providing both visual indication and manual testing capability.

This relay is engineered for efficiency, with a coil resistance of 110 ohms optimising power consumption for the 12V DC coil voltage. Its robust 3PCO (3-Pole Changeover) contact configuration offers great flexibility, allowing it to switch multiple circuits simultaneously—making it ideal for complex control applications where both normally open and normally closed contacts are required.

The plug-in design facilitates easy installation and replacement, minimising downtime during maintenance. The compact form factor ensures it saves valuable space within control panels and enclosures. Constructed to high industrial standards, this relay provides dependable switching performance for automation, machinery, security systems, and vehicle applications.

Key Features & Specifications

• Contact Configuration: 3-Pole Changeover (3PCO)
• Coil Voltage: 12V DC
• Coil Resistance: 110 ohms
• Manual Control: Integrated push button for override
• Status Indication: Built-in flag for visual confirmation
• Mounting: 11-pin plug-in base for easy installation
• Dimensions: 22mm (W) x 33mm (H) x 2mm (D)
• Weight: 85 grams
• Product Series: RSE Series

A dependable choice for engineers and technicians seeking a compact, feature-rich relay for DC control circuits.
