MOLEX KK 254 Vertical Wire-to-Board Header, 3 Way, 2.54mm Pitch
MOLEX KK 254 vertical header (3-way, 2.54mm pitch) with friction lock. For automotive, networking & medical applications. UL/CSA certified.
The MOLEX 22-27-2031 is a high-quality wire-to-board header from the renowned KK 254 series, designed for secure and reliable connections in various electronic applications. It features a vertical orientation and a single-row configuration with friction lock to ensure stable mating with compatible housings (2695, 6471 KK crimp terminal). This header provides excellent performance in demanding environments.
Construction & Features
- Material: Nylon resin (natural white), ensuring durability and insulation
- Contacts: Brass with tin plating for high conductivity and corrosion resistance
- Flammability Rating: Meets UL94 V-0, suitable for safety-critical applications
- Pitch: 2.54mm (mating and termination interface pitch)
- Termination Interface: Through-hole straight for easy PCB mounting
- Certifications: UL E29179, CSA LR19980 approved
- Current Capacity: 4A maximum per contact
- Voltage Rating: 250V maximum
- Temperature Range: -40°C to 80°C
Applications
This header is ideal for Automotive, Communications & Networking, Consumer Electronics, and Medical systems, providing reliable signal connections in compact and high-performance setups.
Note: Market demand has caused extended lead times, with fluctuating delivery dates. This product is exempt from discounts.
- Automotive electronics
- Network/Communication devices
- Consumer electronics
- Medical equipment
- Series: KK 254 (6410)
- No. of Positions: 3
- Orientation: Vertical
- Locking Type: Friction Lock
- Material: Nylon Resin
- Contact Material: Brass (Tin Plated)
- Pitch: 2.54mm
- Termination: Through-Hole
- Current Rating: 4A
- Voltage Rating: 250V
- Operating Temperature: -40°C to 80°C
- Flammability Rating: UL94 V-0
- Contacts: 3
- Rows: 1
- Shroud: Partially Shrouded
- Approvals: UL E29179, CSA LR19980
