MULTICOMP PRO - 120V, 30A, Programmable DC Electronic Load - 150W

The MULTICOMP PRO DC electronic load is a sophisticated, single-channel programmable instrument engineered for demanding middle to high-end applications. It provides comprehensive and flexible testing solutions, easily customised to meet specific user requirements through its intuitive front-panel keypad. This interface allows for straightforward online voltage measurements, adjustments, and the simulation of short circuit tests with minimal setup time.

Featuring a robust set of operational modes, this load supports constant voltage (CV), constant current (CC), constant resistance (CR), and constant power (CW) functions. It excels in specialised testing scenarios including detailed battery analysis, automatic sequence testing, and protective function evaluations such as Over Power Protection (OPP) and Over Current Protection (OCP). The dynamic mode capability, with a frequency response of up to 10kHz, makes it suitable for testing power supplies under transient conditions.

Connectivity is a key strength, with built-in USB, RS232, and LAN interfaces facilitating seamless remote control and integration into automated test systems. The unit also boasts a convenient remote sensing function for accurate voltage measurement and a dedicated current monitoring function. Practical features like a short circuit test mode, a power-off memory function that retains settings, and storage for up to 100 test configurations significantly enhance workflow efficiency and repeatability.

Constructed for reliability, this electronic load is supplied with a UK mains plug (Type G) and is designed for global compatibility. Please note that manufacturer warranty information is excluded from this description.

Variant Details

• Size: 150W
