Multicomp Pro U.Fl to SMA Coaxial Cable, 100mm, 50 Ohm, Black
Multicomp Pro 100mm RF/Coaxial Cable Assembly features 50 Ohm impedance, 1.37mm low-loss cable, ideal for outdoor RF communications.
The Multicomp Pro R-132G7210100CB is a high-quality 100mm RF/Coaxial Cable Assembly, designed for outdoor RF communications. It features a right-angle U.FL plug to SMA bulkhead jack connection, ensuring reliable performance in demanding environments. The cable is encased in a black heat shrink tube and features a U.FL-LP-088 shell and terminal contact for durability.
Constructed from 1.37mm low-loss micro coaxial cable, this assembly guarantees minimal signal degradation, making it ideal for high-frequency applications up to 3 GHz. Its 50 Ohm impedance ensures optimal signal transfer, while the black sheath provides a sleek and professional appearance.
Key Features:
- Low-loss cable design for high-frequency applications
- Robust construction with heat shrink tube for added protection
- Right-angle U.FL plug for easy connection in tight spaces
- SMA bulkhead jack ensures secure and stable connections
- Black sheath for a professional finish
Technical Specifications:
- Frequency range: DC to 3 GHz
- Working voltage: 60Vrms max.
- Dielectric withstanding voltage: 200Vrms max.
- Insulator resistance: 500MΩ min.
- VSWR: 1.4 : 1 max.
- Insertion loss: -1.3dB max.
- Cable length: 100mm
- Colour: Black
Need larger quantities? Need additional quantities? Get in touch and we'll arrange it for you.
- For outdoor RF communications
- For high-frequency applications
- For tight-space installations
- Cable Type: 1.37mm
- Impedance: 50 Ohm
- Frequency Range: DC to 3 GHz
- Working Voltage: 60Vrms max.
- Dielectric Withstanding Voltage: 200Vrms max.
- Insulator Resistance: 500MΩ min.
- VSWR: 1.4 : 1 max.
- Insertion Loss: -1.3dB max.
- Connection Type: 90° U.FL Plug to SMA Bulkhead Jack
- Cable Length: 100mm
- Colour: Black
