PRO ELEC SP211 9-Pole Threaded Inline Socket, IP68, 7-12mm
Durable PRO ELEC 9-pole threaded socket (IP68, 7-12mm cable) for industrial & marine use. 500V/5A rated, -25°C to +85°C.
The PRO ELEC SP211 9-Pole Threaded Inline Socket is a high-performance circular connector designed for robust electrical connections in demanding environments. With an IP68 rating, it offers superior protection against dust and water ingress, making it ideal for outdoor and industrial applications. The threaded coupling ensures a secure and reliable connection that can withstand vibration and mechanical stress.
This socket features 9 solder socket contacts made from brass with gold plating for excellent conductivity and corrosion resistance. The nylon (polyamide) body provides durability and insulation, capable of operating in a wide temperature range from -25°C to +85°C.
Key Features
- Rated Voltage: 500V AC
- Rated Current: 5A
- Threaded Coupling: Ensures secure connection
- Mating Cycles: >500 for long-lasting reliability
- Cable Compatibility: 7-12mm diameter
- Compact Dimensions: 64x29mm (LxØ)
Ideal for use in industrial automation, marine equipment, transportation, and outdoor electronics, this connector ensures consistent performance even in harsh conditions.
Need larger quantities? Need additional quantities? Get in touch and we'll arrange it for you.
Technical Specifications
- Industrial automation systems
- Marine and outdoor electronics
- Transportation equipment
- Harsh environment applications
- Ask Claude, ChatGPT or Perplexity to find the right tool, with our live prices and stock.
- Get a ready-made basket: one link puts everything in your basket here.
- You always pay securely here: your assistant never sees your card.
- Cable Diameter: 7-12mm
- IP Rating: IP68
- Coupling Style: Threaded
- Mating Cycles: >500
- Rated Voltage: 500V AC
- Rated Current: 5A
- Temperature Range: -25°C to +85°C
- Dimensions (LxØ): 64x29mm
- Product Range: SP211 Series
- Connector Type: Cable Mount Receptacle
- Contacts: 9 solder sockets
- Body Material: Nylon (Polyamide)
- Contact Material: Brass with gold plating
- Weight: 30g
