PROTO ADVANTAGE DIP Adaptor for FPC/FFC SMT 0.5mm, 40 Pin
Versatile DIP adaptor for FPC/FFC SMT 0.5mm, 40 pin connections. High-quality construction for reliable prototyping.
The PROTO ADVANTAGE DIP Adaptor for FPC/FFC SMT 0.5mm provides a versatile solution for connecting Surface Mount Technology (SMT) components to Dual In-line Package (DIP) interfaces. Designed for flexibility and reliability, this adaptor features:
- Top-side: Compatible with surface mount connector footprints
- Bottom-side: Equipped with pads for two single row surface mount vertical headers
- Through-hole: Facilitates easy integration into existing PCB designs
Constructed from high-quality 1.5mm thick FR4 epoxy fibreglass, the board ensures durability and stability. It includes double-sided 35µm copper layers, both plated with chemical Ni/Au surface for excellent conductivity and corrosion resistance. The solder stop masks enhance reliability during assembly and use.
Included in the package:
- Printed circuit board (PCB)
- Surface mount pin headers
- 2x assembly spacers
Ideal for prototyping and custom PCB applications, this adaptor supports precise and secure connections for FPC/FFC cables in SMT designs.
- Prototyping PCBs
- FPC/FFC cable connections
- Surface mount technology applications
- Dual in-line package integration
- Material: FR4 Epoxy Fibreglass
- Board Thickness: 1.5mm
- Copper Layer: Double-sided, 35µm
- Surface Finish: Chemical Ni/Au
- Solder Stop Masks: Yes
- Hole Diameter: 1.0mm
- External Dimensions: 52.07mm (H) x 22.86mm (W)
- Board Thickness (Including Copper): 1.6mm
