Vigortronix 6VA PCB Mount Isolation Transformer, 115V/6V, 170g

The Vigortronix VTX-120-4206-406 is a high-quality, compact isolation transformer designed for printed circuit board (PCB) mounting. This 6VA-rated component features a robust open-frame construction and provides reliable electrical isolation, making it a critical safety element in various low-power electronic circuits. With dual 115VAC primary and dual 6VAC secondary windings, it offers flexible configuration options for different input and output requirements.

Manufactured to stringent European safety standards, including EN61558 and EN60950, and marked with the CE conformity symbol, this transformer ensures dependable performance. It is rated for a Class-B temperature class of 130°C and boasts a high dielectric strength of 3750Vrms, enhancing its durability and safety in demanding environments. The 25% regulation specification indicates stable output voltage performance under varying load conditions.

Key Features & Specifications

• Power Rating: 6VA (Volt-Ampere)
• Primary Voltage: Configurable for 2 x 115VAC inputs
• Secondary Voltage: Provides 2 x 6VAC outputs
• Current Rating: 500mA
• Frequency Range: Suitable for 50Hz / 60Hz operation
• Winding Type: Dual primary and dual secondary for design versatility
• Mounting Type: Through-hole for secure PCB soldering
• Safety Standards: Compliant with EN61558 & EN60950, CE marked
• Temperature Class: 130°C Class-B rating
• Dielectric Strength: 3750Vrms isolation
• Dimensions: 33mm (W) x 43mm (H) x 15mm (D)

Ideal for integration into power management systems and industrial control electronics, this transformer is a trusted component for designers and engineers seeking a compact, certified, and reliable isolation solution.
