VIGORTRONIX PCB Transformer 6VA Dual 9V

The VIGORTRONIX PCB Transformer is a compact open-frame safety isolating transformer designed for through-hole PCB mounting. With a power rating of 6VA and dual primary and secondary windings, this transformer offers flexible configuration for a wide range of electronic applications.

Key Features

• Dual primary windings (2 x 115V) allow for series or parallel connection, making it suitable for both 115V and 230V mains supplies.
• Dual secondary windings (2 x 9V) provide a versatile output configuration, with a combined current rating of 333mA.
• Frequency range of 50Hz/60Hz ensures compatibility with standard mains power supplies in the UK and worldwide.
• Open frame safety isolating design offers reliable isolation and protection for sensitive electronics.
• Through-hole mounting enables secure and straightforward PCB assembly.

Applications

This transformer is ideal for use in power supplies, control circuits, audio equipment, and other low-voltage electronic devices where compact, efficient isolation is required. Its dual-winding configuration provides design flexibility, allowing engineers to adapt the transformer to their specific voltage and current needs.

With compact dimensions of just 43mm x 33mm x 15mm and a weight of 170 grams, this VIGORTRONIX transformer integrates easily into space-constrained designs, delivering dependable performance for your projects.
