WAGO Pluggable Terminal Socket Connector, 3-Way, 5mm Pitch, Grey
Universal WAGO 3-way terminal connector with CAGE CLAMP® for secure wire-to-wire & board-to-wire connections.
The WAGO Pluggable Terminal Socket Connector offers a universal connection solution for all conductor types, ensuring flexibility and ease of use. With both vertical and horizontal CAGE CLAMP® actuation, this connector simplifies cable pre-assembly and on-unit wiring.
Designed for both wire-to-wire and board-to-wire connections, the connector includes integrated test ports for convenient diagnostics. Enhanced security is provided with 1 locking latch and 2 coding fingers, ensuring a stable and reliable connection.
Key Features
- Universal compatibility with various conductor types
- Easy cable pre-assembly and wiring
- Suitable for wire-to-wire and board-to-wire connections
- Integrated test ports for easy testing
- Locking latch and coding fingers for secure connections
Applications
- Industrial environments
Technical Specifications
- Pitch Spacing: 5mm
- Number of Positions: 3 Ways
- Wire Size (AWG): 28AWG to 12AWG
- Conductor Area CSA: 2.5mm²
- Wire Connection Method: Clamp
- Rated Current: 16A
- Rated Voltage: 320V
- Product Range: MCS MIDI Classic 231
Need larger quantities? Need additional quantities? Get in touch and we'll arrange it for you.
- Industrial environments
- Pitch Spacing: 5mm
- No. of Positions: 3 Ways
- Wire Size (AWG): 28AWG to 12AWG
- Conductor Area CSA: 2.5mm²
- Wire Connection Method: Clamp
- Rated Current: 16A
- Rated Voltage: 320V
- Product Range: MCS MIDI Classic 231
- Weight: 10g
Always follow local regulations and product guidance.
