Bessey TG20-2K Malleable Cast Iron Screw Clamp, 200mm Capacity

The Bessey TG20-2K Malleable Cast Iron Screw Clamp is the original screw clamp, dating back to 1936, and remains unmatched in quality and performance. Renowned for its durability and precision, this clamp is instantly recognisable by its high-quality profiled rail and distinctive malleable cast iron arms, which are serrated for added reinforcement.

Key Benefits

• Integrated Bessey Anti-Slip System: Ensures maximum safety when clamping with a throat depth of 80 mm or more. A moulded set screw interlocks with the rail serration, preventing any unwanted dislodging or slipping.
• Reinforced Malleable Cast Iron Arms: The fixed and sliding arms are crafted from high-quality, serrated malleable cast iron, offering powerful and rigid clamping. The powder coating provides additional corrosion resistance.
• High-Quality Profiled Rail: The uniquely profiled rail is optimised for clamping applications. Its design resists torsional forces, and the six-face serration further prevents slipping.
• Smooth-Running Spindle: Features a surface-coated spindle with an acme thread for smooth, effortless operation, enhancing work efficiency and comfort.

Applications

Ideal for all tasks requiring strong, rigid clamping, such as woodworking, metalworking, and DIY projects, the Bessey TG20-2K delivers reliable performance in professional and home workshops.

Specifications

• Clamping Force: Up to 6,000 N
• Opening: 200 mm
• Throat Depth: 100 mm
• Rail Dimensions: 27 x 7 mm
• Weight: 1.05 kg
