Bulgin C20 20A Screw Fit Mains Inlet
High-current C20 IEC inlet (16A, 250VAC) with flange mounting, UL/CSA/VDE-approved for industrial & portable devices.
The Bulgin PX0596/63 is a high-current IEC power inlet designed for flange mounting. This C20 IEC inlet connector conforms to EN60320-1 standards, offering a robust electrical rating of 16A, 250VAC, making it suitable for most mains-powered equipment and cable applications. It meets IEC and EN 60320 specifications and carries UL, CSA, and VDE approvals, ensuring reliable performance in demanding environments. Compatible with PX0599 series connectors from Bulgin.
Key Features
- High dielectric strength: 1.5KVAC between contacts, 3KVAC between contacts and accessible surfaces
- Wide operating temperature range: -40°C to 70°C
- Durable construction: Brass with nickel-plated contacts and tin-plated tabs
- Secure termination: Screw terminals for reliable connections
Applications
- Industrial equipment
- Power management systems
- Portable devices
With its flange-mount design and quick-connect compatibility, the Bulgin C20 inlet provides a dependable solution for secure, high-current power connections in various applications.
- Dispatched within 0-2 business days
- Delivery to United States: 3-5 business days*
- Free Shipping Included
- Industrial equipment
- Power management
- Portable devices
- Ask Claude, ChatGPT or Perplexity to find the right tool, with our live prices and stock.
- Get a ready-made basket: one link puts everything in your basket here.
- You always pay securely here: your assistant never sees your card.
- IEC Connector Type: IEC C20 Inlet
- Current Rating: 16A
- Voltage Rating: 250VAC
- Contact Termination Type: Quick Connect
- Connector Mounting: Snap-In, Flange Mount
- Dielectric Strength: 1.5KVAC (between contacts), 3KVAC (contacts & surfaces)
- Operating Temperature: -40°C to 70°C
- Contact Material: Brass (nickel-plated)
- Tab Material: Brass (tin-plated)
- Terminal Type: Screw terminals
