Hirschmann Stackable 4mm Banana Plug Test Lead, 1kV, 32A - Red 1m

The Hirschmann Stackable 4mm Banana Plug Test Lead is a safety adapter designed in accordance with IEC 61010 standards, ensuring reliable and secure measurements. Featuring a 4mm safety plug on one end for onward connection and a 4mm safety socket on the other, this test lead offers exceptional versatility for various testing setups.

Engineered for demanding environments, the lead boasts a highly flexible, double-insulated stranded conductor. The shatter-proof grip sleeve provides durability and a secure grip during use. A standout feature is the built-in colour indicator, which allows for the easy identification of insulation damage, enhancing user safety during operation.

With a rated voltage of 1000V AC/DC and a CAT II measurement category, this test lead is suitable for a wide range of electrical testing applications. It supports a rated current of 32A and features a robust 2.5mm² conductor size. The connectors are crafted from brass with a nickel-plated finish for excellent conductivity and corrosion resistance, while the housing is made from resilient polyamide. The cable is constructed from durable PVC, ensuring long-lasting performance and flexibility in the field.

Variant Details

• Size: 1m
