MOLEX C-Grid III Right Angle Header, 10 Way, 2.54mm Pitch
MOLEX C-Grid III right angle header with gold-plated brass contacts. Ideal for commercial, sensing & consumer electronics applications.
The MOLEX 90122-0765 Header is a 10-circuit, 2-row right angle header with a 2.54mm pitch, designed for seamless signal and wire-to-board applications. Constructed with gold-plated brass contacts for superior conductivity and durability, it is housed in a robust polyester casing, ensuring reliability in various environments.
The C-Grid III design meets the latest industry standards, including DIN41651 and French norm HE-13/14, offering full interchangeability with discrete wire and ribbon cable connectors. Its uniform locking system ensures secure and consistent performance across different housing styles. Additionally, it is fully compatible with Molex's QF-50 product range, making it a versatile choice for multiple applications.
Key Features:
- Current Rating: 3A per contact
- Voltage Rating: 350V
- Temperature Range: -55 to 125°C
- Contact Termination: Through hole, right angle
- Contact Material: Brass with gold plating
Applications:
- Commercial equipment
- Sensing & instrumentation
- Consumer electronics
After bigger quantities? Need extra quantities? Get in touch and we'll organise it for you.
- Dispatched within 0-2 business days
- Delivery to United States: 3-5 business days*
- Free Shipping Included
- Commercial equipment
- Sensing & instrumentation
- Consumer electronics
- Wire-to-board connections
- Ask Claude, ChatGPT or Perplexity to find the right tool, with our live prices and stock.
- Get a ready-made basket: one link puts everything in your basket here.
- You always pay securely here: your assistant never sees your card.
- Circuits: 10
- Rows: 2
- Pitch: 2.54mm
- Termination: Through hole, right angle
- Current rating: 3A per contact
- Voltage rating: 350V
- Temperature range: -55 to 125°C
- Contact material: Brass
- Contact plating: Gold plated
- Housing material: Polyester
- Colour: Black
