MULTICOMP PRO 15-Way Unthreaded IDC D-Sub Socket, Gold Plated
Gold-plated 15-way D-Sub socket for industrial & networking applications. Robust metal construction, 28/26AWG compatible.
The MULTICOMP PRO 15-Way Unthreaded IDC D-Sub Socket is a high-performance connector designed for robust industrial and networking applications. Its gold over nickel-plated phosphor bronze contacts ensure excellent conductivity and corrosion resistance, making it ideal for environments requiring reliable signal transmission.
This 8FSM series female D-subminiature connector features a plastic standard through-hole housing with a PBT + glass-fibre reinforced insulator, providing durability and secure mounting. It is compatible with 28 and 26AWG stranded wire gauges and 1.27mm conductor centre flat cables, offering flexibility for various wiring setups.
Key Specifications
- Maximum contact resistance: ≤15mΩ
- Minimum insulation resistance: ≥1000MΩ
- Dielectric withstanding voltage: 500VAC for one minute
- Operating temperature range: -55°C to 105°C
- Connector mounting: Cable mount
- Contact termination: Insulation displacement (IDC/IDT)
Applications
- Industrial equipment
- Communications and networking devices
- Electrical panels and control systems
Please note: Market demand for this product may result in extended lead times and fluctuating delivery dates. Discounts do not apply.
- Industrial applications
- Communications equipment
- Networking devices
- D Sub Connector Type: Standard
- Gender: Receptacle
- No. of Contacts: 15
- D Sub Shell Size: DA
- Contact Termination Type: IDC / IDT
- Connector Mounting: Cable Mount
- Contact Material: Phosphor Bronze
- Contact Plating: Gold over Nickel
- Connector Body Material: Metal Body
- Housing Material: Plastic (PBT + glass-fibre reinforced)
- Wire Gauge Compatibility: 28 & 26AWG
- Cable Type: 1.27mm conductor centre flat cable
- Weight: 80g
- Product Range: 8F
