NEUTRIK NC6MX 6-Pin XLR Male Plug
Durable NEUTRIK 6-pin XLR male plug with silver-plated contacts, strain relief & die-cast shell. Ideal for professional audio.
The NEUTRIK NC6MX is a 6-pole XLR male cable connector designed for professional audio and consumer electronics applications. With an industry-standard design, this connector is easy to assemble, featuring only 4 parts and no screws for hassle-free installation. Its compact yet robust construction includes a sturdy die-cast shell, a fibreglass-reinforced hard plastic insert, and a chuck-type strain relief for secure cable clamping.
The rubber gland boot offers excellent protection against bending stresses, ensuring long-lasting durability. You can also personalise the connector using coloured rings and boots for easy coding and marking. Suitable for cables with an outer diameter ranging from 3.5mm to 8mm, this XLR plug ensures a reliable connection in various settings.
Key Features:
- Long-lasting and durable construction for repeated use.
- Low contact resistance (≤ 3mΩ) ensures efficient signal transmission.
- Rated voltage (<50V) and rated current (7.5A per contact) for stable performance.
- UL ECBT2.E135070 certified for quality assurance.
- 18AWG (1mm²) wire size compatibility, with >1000 mating cycles for extended lifespan.
- Silver-plated brass solder contacts for superior conductivity.
- Zinc die-cast latch lock and shell with nickel plating for corrosion resistance.
- Meets UL94 HB flammability rating and IP40 protection class.
- Compliant with IEC 61076-2-103 for industry standards.
- Operates in a temperature range of -30°C to 80°C.
Ideal for professional audio setups, studio equipment, and consumer electronics, the NEUTRIK NC6MX delivers reliability and performance in a compact design.
After bigger quantities? Need extra quantities? Get in touch and we'll organise it for you.
Technical Specifications
- Dispatched within 0-2 business days
- Delivery to United States: 3-5 business days*
- Free Shipping Included
- Professional Audio Equipment
- Studio Microphones & Mixers
- Live Sound Systems
- Stage Equipment
- Ask Claude, ChatGPT or Perplexity to find the right tool, with our live prices and stock.
- Get a ready-made basket: one link puts everything in your basket here.
- You always pay securely here: your assistant never sees your card.
- No. of Contacts: 6
- Gender: Plug
- Connector Mounting: Cable Mount
- Contact Plating: Silver Plated
- Connector Body Material: Metal (Zinc Die-Cast)
- Cable Diameter: 3.5mm - 8mm
- Wire Size: 18AWG (1mm²)
- Contact Resistance: ≤3mΩ
- Rated Voltage: <50V
- Current Rating: 7.5A per contact
- Mating Cycles: >1000
- Strain Relief: Chuck Type
- Boot Material: Polyurethane
- Insert Material: Polyamide
- Latch Lock: Zinc Die-Cast
- Shell Material: Zinc Die-Cast (Nickel Plated)
- Flammability Rating: UL94 HB
- Protection Class: IP40
- Certification: UL ECBT2.E135070
- Compliance: IEC 61076-2-103
- Operating Temperature: -30°C to 80°C
- Weight: 30g
