Timco M10 x 100mm Zinc Throughbolts (Pack of 50)
Heavy-duty Timco zinc throughbolts for concrete anchoring. Pack of 50 with hex nut & washer.
The Timco M10 x 100mm Zinc Throughbolts are high-quality torque-controlled fixings designed for robust anchoring applications in concrete. These throughbolts feature a chamfered head design to protect the threads during installation, ensuring a smooth and damage-free process.
Manufactured from cold-formed carbon steel (grade 5.8), these throughbolts are zinc plated and passivated (3-5 microns) for superior corrosion resistance. The special expansion clip allows for rapid installation, making these bolts both efficient and reliable.
Each bolt comes complete with a hex full nut and washer for added convenience. If a torque wrench is unavailable, simply tighten the nut 3 to 4 full turns from finger tight for a secure fit.
Ideal for a wide range of anchoring applications, these throughbolts provide durable and long-lasting performance in demanding environments.
- Shipped within 0-2 business days
- Shipping to United States: 3-5 business days*
- Free Shipping Included
- Concrete anchoring applications
- Structural fixings
- Heavy-duty installations
- Construction projects
- Material: Carbon Steel (Grade 5.8)
- Finish: Zinc Plated & Passivated (3-5 Microns)
- Thread Diameter: M10
- Length: 100mm
- Nut Socket Size: 17mm
- Drill Hole Diameter: 10.0mm
- Fixture Hole Diameter: 12.0mm
- Edge Distance: 70mm
- Max Fixture Thickness: 35mm
- Min Drill Hole Depth: 50mm
- Special Feature: Chamfered head design
- Special Feature: Expansion clip for rapid anchoring
- Weight: 3060g (Pack of 50)
Always follow local regulations and product guidance.
