Timco M12 x 120mm Zinc Throughbolts (Pack of 25)
High-strength zinc throughbolts for concrete. M12x120mm, carbon steel with expansion clip. Pack of 25.
The Timco M12 x 120mm Zinc Throughbolts are high-quality torque-controlled fixings designed for anchoring into concrete and other robust materials. Each bolt comes complete with a hex full nut and washer, ensuring a secure and stable installation.
Key Features:
- Chamfered head design prevents thread damage during installation
- Zinc plated and passivated (3-5 microns) for corrosion resistance
- Manufactured from cold-formed carbon steel (grade 5.8) for strength and durability
- Special expansion clip allows for rapid and hassle-free installation
Installation Note: If no torque wrench is available, simply tighten the nut 3 to 4 full turns from finger-tight position to achieve optimal fixation.
Applications:
- Structural anchoring in concrete
- High-load applications requiring reliable fixing
- Construction and building projects where torque-controlled installation is needed
- Structural steelwork and masonry applications
With their robust construction and corrosion-resistant finish, these throughbolts provide a long-lasting solution for your most demanding anchoring requirements.
Technical Specifications
- Shipped within 0-2 business days
- Shipping to United States: 3-5 business days*
- Free Shipping Included
- Concrete anchoring applications
- Structural steelwork
- High-load fixing situations
- Construction projects
- Ask Claude, ChatGPT or Perplexity to find the right tool, with our live prices and stock.
- Get a ready-made basket: one link puts everything in your basket here.
- You always pay securely here: your assistant never sees your card.
- Thread Diameter: M12
- Length: 120mm
- Nut Socket Size: 19mm
- Material: Carbon Steel (Grade 5.8)
- Finish: Zinc Plated (3-5 microns)
- Drill Hole Diameter: 12.0mm
- Fixture Hole Diameter: 14.0mm
- Edge Distance: 75mm
- Max Fixture Thickness: 45mm
- Min Drill Hole Depth: 60mm
- Special Feature: Expansion clip for rapid installation
- Special Feature: Chamfered head design
- Weight: 2716g
