Timco Zinc Plated Throughbolts - M8 x 100mm (50 Pieces)
Timco zinc plated throughbolts (M8x100mm) for secure concrete anchoring. Includes hex nut & washer. Strong & corrosion-resistant.
The Timco Zinc Plated Throughbolts are high-quality torque-controlled fixings designed for reliable anchoring in concrete and other robust materials. Each bolt is zinc plated and passivated (3-5 microns) to resist corrosion, ensuring long-term durability in various environments. Manufactured from cold-formed carbon steel (grade 5.8), these throughbolts offer exceptional strength and holding power.
Key Features
- Chamfered head design to prevent thread damage during installation
- Includes hex full nut and washer for secure tightening
- Special expansion clip enables rapid and efficient installation
- Suitable for use in concrete and other heavy-duty anchoring applications
Installation Tip
If a torque wrench is unavailable, tighten the nut 3 to 4 full turns from finger tight. This ensures a firm and secure fit without over-tightening.
Specifications
- Thread Diameter: M8
- Length: 100mm
- Nut Socket Size: 13mm
- Material: Carbon Steel (Grade 5.8)
- Finish: Zinc Plated and Passivated
- Drill Hole Diameter: 8.0mm
- Fixture Hole Diameter: 9.0mm
- Edge Distance: 55mm
- Maximum Fixture Thickness: 45mm
- Minimum Drill Hole Depth: 45mm
Technical Specifications
- Shipped within 0-2 business days
- Shipping to Worldwide: 6-7 business days*
- Free Shipping Included
- Concrete anchoring
- Heavy-duty construction
- Structural fixings
- Industrial applications
- Ask Claude, ChatGPT or Perplexity to find the right tool, with our live prices and stock.
- Get a ready-made basket: one link puts everything in your basket here.
- You always pay securely here: your assistant never sees your card.
- Thread Diameter: M8
- Length: 100mm
- Nut Socket Size: 13mm
- Material: Carbon Steel (Grade 5.8)
- Finish: Zinc Plated and Passivated
- Drill Hole Diameter: 8.0mm
- Fixture Hole Diameter: 9.0mm
- Edge Distance: 55mm
- Maximum Fixture Thickness: 45mm
- Minimum Drill Hole Depth: 45mm
- Chamfered Head Design: Prevents thread damage
- Special Expansion Clip: Allows for rapid installation
- Weight: 1957g
